Southwire Company Southwire 22956701 THHN 14 Gauge Building Wire - Stranded Type, White, 500 ft

Description

Voltage for all applications is 600 volts. This cable may be installed without the need for pulling lubricant. FT1 - Sizes through 500 kcmil T90 Nylon - Sizes through 500 kcmil TWN 75 - Sizes through 500 kcmil RoHS Compliant Sunlight Resistant - Marked and listed in all colors 2 AWG and larger. Specifications: Southwire SIMpull THHN or THWN-2 or MTW (also AWM) meets or exceeds all applicable ASTM specifications, UL Standard 83, UL 1581, UL Standard 1063 (MTW), CSA, NOM-ANCE 90 C, Federal Specification A-A-59544, and requirements of the National. When used as Type MTW, conductor is suitable for use in wet locations or when exposed to oil at temperatures not to exceed 60 C or dry locations at temperatures not to exceed 90 C (with ampacity limited to that for 75 C conductor. VW-1 - Sizes 14 through 1 AWG CT - UL 1685, Sizes 1/0 AWG and larger for CT use. When used as Type MTW, conductor is suitable for use in wet locations or when exposed to oil at temperatures not to exceed 60 C or dry locations at temperatures not to exceed 90 C (with ampacity limited to that for 75 C conductor temperature per NFPA 79). Conductor temperatures not to exceed 105 C in dry locations when rated AWM and used as appliance wiring material or when used asT90 Nylon. Some colors standard, some subject. When used as Type THWN-2 or TWN75, conductor is suitable for use in wet or dry locations at temperatures not to exceed 90 C or not to exceed 75 C when exposed to oil.

Key Features

• When used as Type THHN, or T90 Nylon conductor is suitable for use in dry locations at temperatures not to exceed 90 C.
• When used as Type THWN-2 or TWN75, conductor is suitable for use in wet or dry locations at temperatures not to exceed 90 C or not to exceed 75 C when exposed to oil.
• VW-1 - Sizes 14 through 1 AWG CT - UL 1685, Sizes 1/0 AWG and larger for CT use.
• Conductor temperatures not to exceed 105 C in dry locations when rated AWM and used as appliance wiring material or when used asT90 Nylon.
• When used as Type MTW, conductor is suitable for use in wet locations or when exposed to oil at temperatures not to exceed 60 C or dry locations at temperatures not to exceed 90 C (with ampacity limited to that for 75 C conductor.
• FT1 - Sizes through 500 kcmil T90 Nylon - Sizes through 500 kcmil TWN 75 - Sizes through 500 kcmil RoHS Compliant Sunlight Resistant - Marked and listed in all colors 2 AWG and larger.
